RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
PWR ENT RCPT IEC320-C14 PANEL QC
PDF
/
Buying Options
Total Price: USD $16.79
Unit Price: USD $16.7904
≥1 USD $16.7904
≥10 USD $14.70077
≥100 USD $13.15827
Inventory: 162
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Width 65.3mm
Length 50.5mm
Technical
Fuse No
Accomodates a Fuse No
Current - IEC 6A
Filter Type Filtered (EMI, RFI) - Commercial
Voltage - IEC 120/250VAC
Current - UL 6A
Voltage - UL 250VAC
Current 6A
Number of Ports 1
Connector Style IEC 320-C14
Max Current Rating 6A
Max Voltage Rating (AC) 250V
Leakage Current 250μA
ELV Compliant
Panel Cutout Dimensions Rectangular - 35.56mm x 25.65mm
Number of Contacts 3
Approval Agency CSA, UL, VDE
Voltage - Rated AC 250V
Frequency 30MHz
Current Rating 6A
Depth 25.4mm
Orientation Straight
Voltage - Rated DC 250V
Capacitance 47nF
Min Operating Temperature -10°C
Max Operating Temperature 40°C
Number of Positions 3
Connector Type Receptacle, Male Blades
Termination Quick Connect - 0.250 (6.3mm)
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series EBF, Corcom
Published 2001
Packaging Bulk
Physical
Mounting Type Panel Mount, Flange
Mount Flanges, Panel, Screw
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 19 Weeks
