RoHS
RoHS compliant
RoHS compliantPackage 125
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
PWR ENT RCPT PANEL QC
PDF
/
Inventory: 8246
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 31 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Flanges, Panel, Screw, Through Hole
Mounting Type Panel Mount, Flange
Package / Case 125
Technical
Packaging Bulk
Published 2003
Series DA, Corcom
Feature Front or Rear Side Mount
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect - 0.250 (6.3mm)
Connector Type Receptacle, Male Pins
Number of Positions 3
Max Operating Temperature 55°C
Min Operating Temperature -10°C
Gender Male
Voltage - Rated DC 125V
Orientation Straight
Depth 20.57mm
Current Rating 6A
Frequency 200MHz
Approval Agency CSA, UL, VDE
Number of Contacts 3
Panel Cutout Dimensions Variable Size
ELV Compliant
Max Voltage Rating (AC) 125V
Max Current Rating 6A
Connector Style Custom Connection
Number of Ports 1
Current 6A
Wire/Cable Gauge 18 AWG
Voltage - UL 125VDC
Current - UL 6A
Filter Type Filtered (EMI, RFI) - Commercial
Accomodates a Fuse No
Fuse No
Dimensions
Length 50.29mm
Width 54.61mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
