3EGG1-2
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
PWR ENT MOD RCPT IEC320-C14 PNL
PDF
/
Buying Options
Total Price: USD $6.35
Unit Price: USD $6.345246
≥1 USD $6.345246
Inventory: 3004
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Width 44.7mm
Height 32.8mm
Technical
Fuse Holder, Drawer Fuse Holder
Fuse Yes
Accomodates a Fuse Yes (Fuse Not Included)
Current - IEC 3A
Filter Type Filtered (EMI, RFI) - Commercial
Voltage - IEC 120/250VAC
Current 3A
Number of Ports 1
Connector Style IEC 320-C14
Max Current Rating 3A
Max Voltage Rating (AC) 250V
Leakage Current 250μA
ELV Compliant
Panel Cutout Dimensions Rectangular - 28.96mm x 33.02mm
Number of Contacts 3
Approval Agency CSA, UL, VDE
Voltage - Rated AC 250V
Frequency 30MHz
Current Rating 3A
Depth 54.5mm
Orientation Straight
Voltage - Rated DC 250V
Capacitance 101nF
Voltage - Rated 250V
Gender Male
Min Operating Temperature -10°C
Max Operating Temperature 40°C
Number of Positions 3
Connector Type Receptacle, Male Blades - Module
Termination Quick Connect - 0.250 (6.3mm)
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series GG, Corcom
Published 2006
Packaging Bulk
Physical
Package / Case Module
Mounting Type Panel Mount, Flange
Mount Flanges, Panel, Screw
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 16 Weeks
