1EGG8C-1
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
AC Power Entry Modules IA IEC - WIRE LEAD GRND CHOK FLNGE MNT
PDF
/
Buying Options
Total Price: USD $15.33
Unit Price: USD $15.329405
≥1 USD $15.329405
≥10 USD $14.461705
≥100 USD $13.643116
≥500 USD $12.870856
≥1000 USD $12.142321
Inventory: 1191
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Flanges, Panel, Screw
Mounting Type Panel Mount, Flange
Package / Case Module
Technical
Packaging Bulk
Published 2009
Series GG, Corcom
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Wire Leads
Connector Type Receptacle, Male Blades - Module
Number of Positions 3
Max Operating Temperature 40°C
Min Operating Temperature -10°C
Capacitance 101nF
Voltage - Rated DC 250V
Orientation Straight
Current Rating 1A
Frequency 30MHz
Voltage - Rated AC 250V
Approval Agency CSA, UL, VDE
Number of Contacts 3
Panel Cutout Dimensions Rectangular - 28.96mm x 33.02mm
ELV Compliant
Leakage Current 250μA
Max Voltage Rating (AC) 250V
Max Current Rating 1A
Connector Style IEC 320-C14
Number of Ports 1
Current 1A
Voltage - IEC 120/250VAC
Filter Type Filtered (EMI, RFI) - Commercial
Current - IEC 1A
Accomodates a Fuse Yes (Fuse Not Included)
Fuse Yes
Fuse Holder, Drawer Fuse Holder
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
