GRF4.0419.013.C
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
Power Entry Module Filtered M 3 POS 250VAC 15A RA 1 Port
PDF
/
Inventory: 7943
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Package / Case Module
Shell Material POLYETHYLENE
Housing Material Thermoplastic
Weight 37.000012g
Technical
Packaging Bulk
Series GRF4
Feature Shielded
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Quick Connect - 0.189 (4.8mm)
Connector Type Receptacle, Male Blades
Number of Positions 3
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Gender Male
Voltage - Rated 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Right Angle
Ingress Protection IP40
Depth 29mm
Current Rating 10A
Frequency 60Hz
Voltage - Rated AC 250V
Approval Agency CSA, UL, VDE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Panel Cutout Dimensions Rectangular - 30.50mm x 20.80mm
Max Voltage Rating (AC) 250V
Max Current Rating 15A
Connector Style IEC 320-C14
Number of Ports 1
Current 15A
Voltage - UL 125VAC
Filter Type Filtered (EMI, RFI) - Commercial
Accomodates a Fuse No
Dimensions
Height 59.3mm
Length 31.4mm
Width 31.4mm
Panel Thickness 0.059 1.50mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
