DD12.9111.111
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
PWR ENT MOD RCPT IEC320-C14 PNL
PDF
/
Buying Options
Total Price: USD $18.87
Unit Price: USD $18.8672
≥1 USD $18.8672
≥10 USD $18.8672
Inventory: 1101
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Flanges, Panel, Screw
Mounting Type Panel Mount, Flange
Package / Case Module
Shell Material POLYETHYLENE
Housing Material Thermoplastic
Weight 85.048569g
Technical
Packaging Bulk
Series DD12
Feature Earth Line Choke, Shielded, V-Lock Notch
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Quick Connect - 0.250 (6.3mm)
ECCN Code EAR99
Connector Type Receptacle, Male Blades - Module
Resistance 1MOhm
Number of Positions 3
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Gender Male
Capacitance 100nF
Voltage - Rated DC 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Ingress Protection IP40
Depth 60.9mm
Current Rating 10A
Voltage - Rated AC 250V
Approval Agency cURus, ENEC
Mating Information MULTIPLE MATING PARTS AVAILABLE
Panel Cutout Dimensions Rectangular - 29.80mm x 49.30mm
Inductance 300 μH
Max Voltage Rating (AC) 250V
Max Current Rating 10A
Coupling Type SNAP
Connector Style IEC 320-C14
Number of Ports 1
Voltage - IEC 250VAC
Filter Type Filtered (EMI, RFI) - Commercial
Accomodates a Fuse Yes (Fuse Not Included)
Fuse Yes
Fuse Holder, Drawer Drawer Sold Separate
Switch Features Switch On-Off
Dimensions
Height 31.5mm
Length 66mm
Width 66mm
Panel Thickness 0.315 8.00mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
