DD12.4111.111
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
Switch On-Off DD12 ROHS3Compliant Straight Power Entry Connector Receptacle, Male Blades - Module UL94V-0 1MOhm 1.5mH 100nF
PDF
/
Buying Options
Total Price: USD $18.87
Unit Price: USD $18.8672
≥1 USD $18.8672
≥10 USD $18.8672
Inventory: 68
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Panel Thickness 0.315 8.00mm
Width 66mm
Height 31.5mm
Technical
Switch Features Switch On-Off
Fuse Holder, Drawer Drawer Sold Separate
Fuse Yes
Accomodates a Fuse Yes (Fuse Not Included)
Filter Type Filtered (EMI, RFI) - Commercial
Voltage - IEC 250VAC
Current 4A
Number of Ports 1
Connector Style IEC 320-C14
Coupling Type SNAP
Max Current Rating 4A
Max Voltage Rating (AC) 250V
Inductance 1.5 mH
Panel Cutout Dimensions Rectangular - 29.80mm x 49.30mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency cURus, ENEC
Voltage - Rated AC 250V
Current Rating 4A
Depth 60.9mm
Ingress Protection IP40
Orientation Straight
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Capacitance 100nF
Gender Male
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Number of Positions 3
Resistance 1MOhm
Connector Type Receptacle, Male Blades - Module
ECCN Code EAR99
Termination Quick Connect - 0.250 (6.3mm)
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Feature Earth Line Choke, Shielded, V-Lock Notch
Series DD12
Packaging Bulk
Physical
Weight 85.048569g
Housing Material Thermoplastic
Shell Material POLYETHYLENE
Package / Case Module
Mounting Type Panel Mount, Flange
Mount Flanges, Panel, Screw
Supply Chain
Factory Lead Time 10 Weeks
