DC21.0023.1111
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
PWR ENT MOD RCPT IEC320-C14 PNL
PDF
/
Buying Options
Total Price: USD $14.63
Unit Price: USD $14.6256
≥1 USD $14.6256
≥10 USD $11.3784
≥100 USD $9.4028
Inventory: 122
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Flanges, Panel, Screw, Through Hole
Mounting Type Panel Mount, Flange; Through Hole, Right Angle
Package / Case Module
Shell Material POLYETHYLENE
Housing Material Thermoplastic
Weight 28.349523g
Technical
Packaging Bulk
Series DC21
Feature Terminating Cover
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Solder
ECCN Code EAR99
Connector Type Receptacle, Male Blades - Module
Type Switch
Number of Positions 3
Max Operating Temperature 70°C
Min Operating Temperature -25°C
Gender Male
Voltage - Rated DC 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Ingress Protection IP40
Depth 31.75mm
Current Rating 10A
Voltage - Rated AC 125V
Approval Agency cULus, ENEC
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body/Shell Style SOCKET
Max Voltage Rating (AC) 250V
Max Current Rating 15A
Connector Style IEC 320-C14
Number of Ports 1
Current 11A
Number of Poles 2
Throw Configuration DPST
Voltage - UL 125VAC
Voltage - IEC 250VAC
Filter Type Unfiltered - Commercial
Current - IEC 10A
Illumination Color Red
Accomodates a Fuse No
Switch Features Switch On-Off, Illuminated
Dimensions
Length 52mm
Panel Thickness 0.138 3.50mm
Compliance
Material Flammability Rating UL94 V-0
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
