CEB0.6100.151
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
CE ROHS3Compliant Straight GENERAL PURPOSE Power Entry Connector Receptacle, Male Blades - Module UL94V-0 85C 2A 250V
PDF
/
Buying Options
Total Price: USD $119.39
Unit Price: USD $119.3925
≥1 USD $119.3925
≥200 USD $47.638577
≥500 USD $46.047342
≥1000 USD $45.260915
Inventory: 1078
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Technical
Fuse Holder, Drawer Drawer Sold Separate
Fuse Yes
Accomodates a Fuse Yes (Fuse Not Included)
Voltage - UL 125VAC
Number of Ports 1
Connector Style IEC 320-C14
Coupling Type SNAP
Max Current Rating 2A
Max Voltage Rating (AC) 250V
Panel Cutout Dimensions Rectangular - 28.50mm x 53.50mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency cULus, ENEC
Ingress Protection IP40
Orientation Straight
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Number of Positions 3
Connector Type Receptacle, Male Blades - Module
Termination Quick Connect - 0.189 (4.8mm)
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Feature Voltage Selector
Series CE
Packaging Bulk
Physical
Weight 82.000003g
Shell Material POLYETHYLENE
Package / Case Module
Mounting Type Panel Mount, Flange
Mount Flanges, Panel
Supply Chain
Factory Lead Time 10 Weeks
