C22F.1002
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
C22F ROHS3Compliant Straight IP40 Power Entry Connector Receptacle, Male Blades UL94V-0 600muH 100C 20A
PDF
/
Inventory: 3742
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Flanges, Panel, Screw
Mounting Type Panel Mount, Flange
Package / Case Module
Housing Material Thermoplastic
Technical
Packaging Bulk
Series C22F
Feature Shielded
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Solder Eyelet
ECCN Code EAR99
Connector Type Receptacle, Male Blades
Number of Positions 3
Max Operating Temperature 100°C
Min Operating Temperature -25°C
Gender Male
Voltage - Rated DC 250V
Orientation Straight
Ingress Protection IP40
Depth 64.65mm
Current Rating 16A
Voltage - Rated AC 250V
Approval Agency cULus, ENEC
Panel Cutout Dimensions Rectangular - 26.80mm x 34.80mm
Inductance 600 μH
Connector Style IEC 320-C22
Current 20A
Voltage - IEC 250VAC
Filter Type Filtered (EMI, RFI) - Commercial, Medical
Current - IEC 16A
Accomodates a Fuse No
Dimensions
Height 53mm
Length 68.5mm
Width 30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
