C22F.0003
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
PWR ENT RCPT IEC320-C22 PNL SLDR
PDF
/
Buying Options
Total Price: USD $75.25
Unit Price: USD $75.248864
≥1 USD $75.248864
≥200 USD $30.026023
≥500 USD $29.021655
≥1000 USD $28.526691
Inventory: 1153
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Flanges, Panel, Screw
Mounting Type Panel Mount, Flange
Package / Case Module
Housing Material Thermoplastic
Technical
Packaging Bulk
Series C22F
Feature Shielded
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Solder Eyelet
ECCN Code EAR99
Connector Type Receptacle, Male Blades
Number of Positions 3
Max Operating Temperature 100°C
Min Operating Temperature -25°C
Gender Male
Voltage - Rated DC 250V
Orientation Straight
Ingress Protection IP40
Depth 64.65mm
Current Rating 20A
Voltage - Rated AC 250V
Approval Agency cULus, ENEC
Panel Cutout Dimensions Rectangular - 26.80mm x 34.80mm
Inductance 300 μH
Connector Style IEC 320-C22
Current 20A
Voltage - IEC 250VAC
Filter Type Filtered (EMI, RFI) - Commercial
Current - IEC 16A
Accomodates a Fuse No
Dimensions
Height 53mm
Length 68.5mm
Width 30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
