C20F.0023

Schurter Inc.
RoHS
RoHS RoHS compliant
Package Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description C20F ROHS3Compliant GENERAL PURPOSE MULTIPLE MATING PARTS AVAILABLE Power Entry Connector Receptacle, Male Blades UL94V-0 1MOhm 20A 250V
PDF
/
Buying Options
Total Price: USD $30.34
Unit Price: USD $30.3424
≥1 USD $30.3424
≥10 USD $20.945056
Inventory: 76
Minimum: 1
-
+

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Width 53mm
Height 30mm

Technical

Accomodates a Fuse No
Current - IEC 16A
Filter Type Filtered (EMI, RFI) - Commercial
Voltage - IEC 250VAC
Number of Poles 3
Current 20A
Connector Style IEC 320-C20
Coupling Type SNAP
Max Voltage Rating (AC) 250V
Panel Cutout Dimensions Rectangular - 36.40mm x 28.30mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency cULus, VDE
Voltage - Rated AC 250V
Current Rating 20A
Depth 78.8mm
Ingress Protection IP40
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Gender Male
Resistance 1MOhm
Connector Type Receptacle, Male Blades
ECCN Code EAR99
Termination Solder Eyelet
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Feature Shielded
Series C20F
Packaging Bulk

Physical

Weight 105g
Shell Material POLYETHYLENE
Package / Case Module
Mounting Type Panel Mount, Flange
Mount Flanges, Panel, Screw

Supply Chain

Factory Lead Time 11 Weeks
