6653.3100
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
Power Entry Connector Inlet
PDF
/
Inventory: 5095
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Technical
Accomodates a Fuse No
Current - IEC 16A
Filter Type Unfiltered - Commercial
Voltage - IEC 250VAC
Current 20A
Connector Style IEC 320-2-2/J
Coupling Type SNAP
Panel Cutout Dimensions Rectangular - 37.60mm x 29.50mm
Operating Temperature (Min) -25°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 70°C
Body Length or Diameter 2.126 inch
Approval Agency CCC, CSA, ENEC, UL
Reference Standard CCC, ENEC
Ingress Protection IP30
Total Number of Contacts 3
Option GENERAL PURPOSE
Number of Positions 3
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Quick Connect - 0.189 (4.8mm)
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Obsolete
Pbfree Code yes
Series 723
Packaging Bulk
Physical
Shell Material THERMOPLASTIC
Package / Case Module
Mounting Type Panel Mount, Flange
Mount Flanges, Panel
