6610.1154
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
AC Power Entry Modules 6610 APLIANCE OUTLET 10A 70 deg C
PDF
/
Buying Options
Total Price: USD $1.39
Unit Price: USD $1.3904
≥1 USD $1.3904
≥10 USD $1.12112
≥100 USD $1.01464
≥500 USD $0.980109
Inventory: 85
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Cable, Panel, Snap in
Mounting Type Panel Mount, Snap-In
Shell Material POLYETHYLENE
Weight 16.300012g
Technical
Packaging Bulk
Series 6610
Feature Light Pipe
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination IDC
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 3
Max Operating Temperature 70°C
Min Operating Temperature -25°C
Gender Receptacle
Voltage - Rated DC 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Right Angle
Ingress Protection IP40
Current Rating 15A
Voltage - Rated AC 250V
Approval Agency CCC, cULus, ENEC
Mating Information MULTIPLE MATING PARTS AVAILABLE
Panel Cutout Dimensions Rectangular - 32.80mm x 24.30mm
Voltage 250V
Max Voltage Rating (AC) 250V
Max Current Rating 15A
Connector Style IEC 320-2-2/F
Current 15A
Wire/Cable Gauge 12 AWG
Voltage - IEC 250VAC
Filter Type Unfiltered - Commercial
Current - IEC 10A
Accomodates a Fuse No
Dimensions
Panel Thickness 0.059 1.50mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
