6200.4120
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
Connector: AC supply; socket; male; 10A; 250VAC; IEC 60320; max2mm
PDF
/
Buying Options
Total Price: USD $2.9
Unit Price: USD $2.8952
≥1 USD $2.8952
≥10 USD $2.49656
≥100 USD $2.32848
≥500 USD $2.0196
Inventory: 116
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Panel Thickness 0.079 2.00mm
Length 30mm
Technical
Fuse Holder, Drawer Fuse Holder
Fuse Yes
Accomodates a Fuse Yes (Fuse Not Included)
Filter Type Unfiltered - Commercial
Voltage - IEC 250VAC
Current 10A
Number of Ports 1
Connector Style IEC 320-C14
Max Current Rating 10A
Max Voltage Rating (AC) 250V
Voltage 250V
Body/Shell Style SOCKET
Panel Cutout Dimensions Rectangular - 27.50mm x 31.50mm
Approval Agency CCC, CSA, ENEC, UL
Current Rating 10A
Depth 25.5mm
Ingress Protection IP40
Orientation Straight
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating TIN
Voltage - Rated DC 250V
Voltage - Rated 250V
Min Operating Temperature -25°C
Max Operating Temperature 70°C
Number of Positions 3
Connector Type Receptacle, Male Blades - Module
ECCN Code EAR99
Termination Solder Eyelet
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 6200
Packaging Bulk
Physical
Weight 12.000013g
Housing Material Thermoplastic
Shell Material POLYETHYLENE
Package / Case Module
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Plating Tin
Supply Chain
Factory Lead Time 13 Weeks
