6162.0076

Schurter Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description Power Entry Connectors Module
PDF
/
Inventory: 2505
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Technical

Accomodates a Fuse No
Current - IEC 10A
Filter Type Unfiltered - Commercial
Voltage - IEC 250VAC
Current 15A
Connector Style IEC 320-C18
Coupling Type SNAP
Panel Cutout Dimensions Rectangular - 27.00mm x 19.60mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency cCSAus, ENEC, UL
Ingress Protection IP20
Orientation Straight
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Number of Positions 2
Connector Type Receptacle, Male Blades
Termination Quick Connect - 0.250 (6.3mm)
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Obsolete
Series 6066
Packaging Bulk

Physical

Weight 9.209995g
Mounting Type Panel Mount, Flange
Mount Flanges, Panel, Through Hole
