6162.0007
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
PWR ENT RCPT IEC320-C14 PNL SLDR
PDF
/
Buying Options
Total Price: USD $1.75
Unit Price: USD $1.7512
≥1 USD $1.7512
≥10 USD $1.4872
≥100 USD $1.38776
≥500 USD $1.2562
Inventory: 234
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Shell Material PA6
Weight 9.199987g
Technical
Packaging Bulk
Series 1061
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Solder Eyelet
ECCN Code EAR99
Connector Type Receptacle, Male Blades
Number of Positions 3
Gender Male
Voltage - Rated 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Ingress Protection IP20
Approval Agency CCC, cCSAus, ENEC, UL
Mating Information MULTIPLE MATING PARTS AVAILABLE
Connector Style IEC 320-C14
Current 15A
Voltage - IEC 250VAC
Filter Type Unfiltered - Commercial
Current - IEC 10A
Accomodates a Fuse No
Dimensions
Panel Thickness 0.031 ~ 0.079 0.79mm ~ 2.00mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
