6110.3200

Schurter Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description CONNECTOR, IEC POWER ENTRY, PLUG, 15A - More Details
PDF
/
Buying Options
Total Price: USD $2.23
Unit Price: USD $2.2264
≥1 USD $2.2264
≥10 USD $1.83128
≥100 USD $1.72568
≥500 USD $1.6104
Inventory: 111
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 9 Weeks

Physical

Mount Flanges, Panel, Screw
Mounting Type Panel Mount, Flange
Shell Material POLYETHYLENE
Weight 8.300003g
Body Material Thermoplastic

Technical

Packaging Bulk
Series 6110-3
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Quick Connect - 0.189 (4.8mm)
ECCN Code EAR99
Connector Type Receptacle, Male Blades
Number of Positions 3
Max Operating Temperature 120°C
Min Operating Temperature -25°C
Gender Male
Voltage - Rated DC 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Ingress Protection IP40
Depth 28.5mm
Current Rating 15A
Voltage - Rated AC 250V
Approval Agency CCC, cULus, ENEC
Mating Information MULTIPLE MATING PARTS AVAILABLE
Panel Cutout Dimensions Rectangular - 27.50mm x 20.00mm
Body/Shell Style SOCKET
Max Voltage Rating (AC) 250V
Max Current Rating 15A
Coupling Type SNAP
Connector Style IEC 320-C16
Number of Ports 1
Current 15A
Voltage - IEC 250VAC
Filter Type Unfiltered - Commercial
Current - IEC 10A
Accomodates a Fuse No

Dimensions

Length 48mm

Compliance

Material Flammability Rating UL94 V-0
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
