6100.3200
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
PWR ENT RCPT IEC320-C14 PANEL QC
PDF
/
Buying Options
Total Price: USD $1.01
Unit Price: USD $1.012
≥1 USD $1.012
≥10 USD $0.8756
≥100 USD $0.81664
≥500 USD $0.62832
≥1000 USD $0.5742
Inventory: 1260
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Material Flammability Rating UL94 V-0
Dimensions
Length 28.5mm
Height 23mm
Technical
Accomodates a Fuse No
Current - IEC 10A
Filter Type Unfiltered - Commercial
Voltage - IEC 250VAC
Number of Poles 3
Current 15A
Number of Ports 1
Connector Style IEC 320-C14
Coupling Type SNAP
Max Current Rating 15A
Max Voltage Rating (AC) 250V
Body/Shell Style SOCKET
Panel Cutout Dimensions Variable Size
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency CCC, cULus, ENEC
Voltage - Rated AC 250V
Current Rating 10A
Depth 25.5mm
Ingress Protection IP40
Orientation Straight
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Gender Male
Color Black
Min Operating Temperature -25°C
Max Operating Temperature 70°C
Connector Type Receptacle, Male Blades
ECCN Code EAR99
Termination Quick Connect - 0.189 (4.8mm)
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Feature Front or Rear Side Mount
Series 6100-3
Packaging Bulk
Physical
Weight 8.199986g
Material Thermoplastic
Package / Case Module
Mounting Type Panel Mount, Flange
Mount Flanges, Panel, Screw
Supply Chain
Factory Lead Time 14 Weeks
