5130.2300
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
TIN 5130 ROHS3Compliant Straight Power Entry Connector Receptacle, Male Blades UL94V-0 600muH 85C 20A
PDF
/
Buying Options
Total Price: USD $14.4
Unit Price: USD $14.3968
≥1 USD $14.3968
Inventory: 63
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Package / Case Module
Housing Material Steel
Weight 85.048569g
Technical
Packaging Bulk
Series 5130
Feature Shielded
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Quick Connect - 0.250 (6.3mm)
ECCN Code EAR99
Connector Type Receptacle, Male Blades
Number of Positions 3
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Gender Male
Voltage - Rated 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Ingress Protection IP40
Depth 67.5mm
Current Rating 16A
Shell Finish TIN
Voltage - Rated AC 125V
Approval Agency cULus, ENEC
Mating Information MULTIPLE MATING PARTS AVAILABLE
Panel Cutout Dimensions Rectangular - 35.00mm x 27.00mm
Inductance 600 μH
Max Voltage Rating (AC) 250V
Max Current Rating 16A
Connector Style IEC 320-C20
Number of Ports 1
Current 20A
Voltage - IEC 250VAC
Filter Type Filtered (EMI, RFI) - Commercial, Medical
Accomodates a Fuse No
Dimensions
Height 30.6mm
Width 39mm
Panel Thickness 0.031 ~ 0.118 0.79mm ~ 3.00mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
