5120.0200.0
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
TIN 5120 ROHS3Compliant Straight Power Entry Connector Receptacle, Male Blades UL94V-0 12mH 100nF 85C
PDF
/
Buying Options
Total Price: USD $14.19
Unit Price: USD $14.185885
≥1 USD $14.185885
≥200 USD $5.661225
≥500 USD $5.470854
≥1000 USD $5.377638
Inventory: 1477
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Width 48.6mm
Height 24.6mm
Technical
Accomodates a Fuse No
Voltage - IEC 250VAC
Current 1A
Number of Ports 1
Connector Style IEC 320-C14
Coupling Type SNAP
Max Current Rating 1A
Max Voltage Rating (AC) 250V
Inductance 12 mH
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency CCC, cULus, ENEC
Voltage - Rated AC 250V
Shell Finish TIN
Current Rating 1A
Depth 54.5mm
Ingress Protection IP40
Orientation Straight
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating TIN/TIN COPPER
Voltage - Rated DC 250V
Capacitance 100nF
Gender Male
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Number of Positions 3
Connector Type Receptacle, Male Blades
Termination Quick Connect - 0.250 (6.3mm)
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Pbfree Code yes
Feature Shielded
Series 5120
Packaging Bulk
Physical
Weight 41.999989g
Housing Material Steel
Package / Case Module
Mount Flanges, Panel, Screw
Supply Chain
Factory Lead Time 12 Weeks
