5110.0143.3
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
AC Power Entry Modules SNAP-IN 1A
PDF
/
Buying Options
Total Price: USD $15.77
Unit Price: USD $15.7696
≥1 USD $15.7696
≥10 USD $13.687696
≥100 USD $13.00376
≥500 USD $12.3596
Inventory: 101
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Package / Case Module
Shell Material POLYETHYLENE
Housing Material Thermoplastic
Weight 35.000009g
Technical
Packaging Bulk
Series 5110
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Quick Connect - 0.250 (6.3mm)
ECCN Code EAR99
Connector Type Receptacle, Male Blades
Resistance 1MOhm
Number of Positions 3
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Gender Male
Voltage - Rated DC 250V
Contact Finish - Mating TIN/TIN COPPER
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Ingress Protection IP40
Depth 55.7mm
Current Rating 1A
Voltage - Rated AC 125V
Approval Agency CCC, cULus, ENEC
Mating Information MULTIPLE MATING PARTS AVAILABLE
Panel Cutout Dimensions Rectangular - 29.00mm x 21.00mm
Max Voltage Rating (AC) 250V
Max Current Rating 1A
Connector Style IEC 320-C14
Number of Ports 1
Current 1A
Number of Poles 2
Voltage - UL 125VAC
Voltage - IEC 250VAC
Filter Type Filtered (EMI, RFI) - Commercial, Medical
Accomodates a Fuse No
Dimensions
Height 23mm
Width 36mm
Panel Thickness 0.031 ~ 0.118 0.79mm ~ 3.00mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
