5110.0133.3
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
AC Power Entry Modules SCREW ON 1A
PDF
/
Buying Options
Total Price: USD $17.36
Unit Price: USD $17.364909
≥1 USD $17.364909
≥10 USD $16.38199
≥100 USD $15.45471
≥500 USD $14.579915
≥1000 USD $13.754638
Inventory: 1083
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Width 48.4mm
Length 48.4mm
Height 23mm
Technical
Accomodates a Fuse No
Filter Type Filtered (EMI, RFI) - Commercial, Medical
Voltage - IEC 250VAC
Voltage - UL 125VAC
Current 1A
Number of Ports 1
Connector Style IEC 320-C14
Coupling Type SCREW
Max Current Rating 1A
Max Voltage Rating (AC) 250V
Panel Cutout Dimensions Rectangular - 29.00mm x 21.00mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency CCC, cULus, ENEC
Current Rating 1A
Depth 55.6mm
Ingress Protection IP40
Orientation Straight
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 250V
Gender Male
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Number of Positions 3
Connector Type Receptacle, Male Blades
Termination Quick Connect - 0.250 (6.3mm)
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Pbfree Code yes
Series 5110
Packaging Bulk
Physical
Weight 35.000009g
Housing Material Thermoplastic
Shell Material POLYETHYLENE
Package / Case Module
Mounting Type Panel Mount, Flange
Mount Flanges, Panel
Supply Chain
Factory Lead Time 15 Weeks
