5003.045B.1
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
TIN 5003 ROHS3Compliant GENERAL PURPOSE Power Entry Connector Receptacle, Male Pins UL94V-0 15A 125V 61mm
PDF
/
Buying Options
Total Price: USD $11.62
Unit Price: USD $11.616
≥1 USD $11.616
Inventory: 44
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Panel Thickness 0.315 8.00mm
Width 48.6mm
Height 24.6mm
Technical
Accomodates a Fuse No
Filter Type Filtered (EMI, RFI) - Commercial
Voltage - IEC 125VDC
Max Voltage Rating (DC) 125V
Current 15A
Connector Style Special - Molex HCS
Coupling Type SNAP
Panel Cutout Dimensions Rectangular - 30.30mm x 22.80mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency cULus, ENEC
Shell Finish TIN
Current Rating 15A
Depth 61mm
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature STANDARDS: UL 94V-0; VDE
Voltage - Rated 125V
Gender Male
Number of Positions 3
Connector Type Receptacle, Male Pins
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Feature Shielded
Series 5003
Packaging Bulk
Physical
Weight 41.999989g
Shell Material METALLIC/STEEL
Package / Case Module
Mounting Type Panel Mount, Flange; Through Hole
Mount Flanges, Panel, Through Hole
Supply Chain
Factory Lead Time 12 Weeks
