4798.9100
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
Conn Inlets PL 3 POS Faston ST Panel Mount 3 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $2.33
Unit Price: USD $2.332
≥1 USD $2.332
≥10 USD $1.76704
≥100 USD $1.439856
Inventory: 115
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Technical
Accomodates a Fuse No
Current - IEC 16A
Filter Type Unfiltered - Commercial
Voltage - IEC 250VAC
Current 20A
Connector Style IEC 320-C20
Coupling Type SNAP
Max Current Rating 20A
Max Voltage Rating (AC) 250V
Panel Cutout Dimensions Rectangular - 32.60mm x 24.50mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency CCC, cULus, ENEC
Ingress Protection IP40
Orientation Straight
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 250V
Gender Male
Min Operating Temperature -25°C
Max Operating Temperature 70°C
Number of Positions 3
Connector Type Receptacle, Male Blades
Termination Quick Connect - 0.189 (4.8mm)
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
JESD-609 Code e3
Series 4798
Packaging Bulk
Physical
Weight 99.988768mg
Shell Material POLYETHYLENE
Mounting Type Panel Mount, Flange
Mount Flanges, Panel, Screw
Supply Chain
Factory Lead Time 23 Weeks
