4797.3125
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
4797 ROHS3Compliant Straight GENERAL PURPOSE Power Entry Connector Receptacle, Female Sockets UL94V-0 20A 250VAC 0.031-0.118 0.79mm-3.00mm
PDF
/
Buying Options
Total Price: USD $3.14
Unit Price: USD $3.1416
≥1 USD $3.1416
≥10 USD $2.38744
≥100 USD $1.91136
≥500 USD $1.51624
≥1000 USD $1.4388
Inventory: 83
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 23 Weeks
Physical
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Shell Material POLYETHYLENE
Weight 18.499992g
Technical
Packaging Bulk
Series 4797
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Solder Eyelet
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 3
Gender Female
Voltage - Rated 250V
Voltage - Rated DC 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Current Rating 50A
Approval Agency CCC, cURus, ENEC
Panel Cutout Dimensions Rectangular - 37.60mm x 29.50mm
Connector Style IEC 320-2-2/J
Current 20A
Voltage - IEC 250VAC
Filter Type Unfiltered - Commercial
Current - IEC 16A
Accomodates a Fuse No
Dimensions
Panel Thickness 0.031 ~ 0.118 0.79mm ~ 3.00mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
