4793.3200
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
Conn Inlets PL 3 POS Solder ST Panel Mount 3 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $2.33
Unit Price: USD $2.332
≥1 USD $2.332
≥10 USD $1.76704
≥100 USD $1.439856
Inventory: 600
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Panel Thickness 0.039 1.00mm
Length 36mm
Technical
Accomodates a Fuse No
Current - IEC 16A
Filter Type Unfiltered - Commercial
Voltage - IEC 250VAC
Current 20A
Number of Ports 1
Connector Style IEC 320-C20
Max Current Rating 20A
Max Voltage Rating (AC) 250V
Body/Shell Style SOCKET
Panel Cutout Dimensions Rectangular - 32.00mm x 24.00mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency CCC, cULus, ENEC
Depth 31.3mm
Ingress Protection IP30
Orientation Straight
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 250V
Gender Male
Min Operating Temperature -25°C
Max Operating Temperature 70°C
Number of Positions 3
Connector Type Receptacle, Male Blades
ECCN Code EAR99
Termination Solder Eyelet
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Pbfree Code yes
Series 4793
Packaging Bulk
Physical
Weight 12.15001g
Housing Material Thermoplastic
Shell Material THRMOPLASTIC
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Supply Chain
Factory Lead Time 12 Weeks
