4787.2000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
OUTLET, IEC, BACKPLANE, F, 4787, 10A
PDF
/
Buying Options
Total Price: USD $2.12
Unit Price: USD $2.1208
≥1 USD $2.1208
≥10 USD $1.8392
≥100 USD $1.5774
Inventory: 251
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Material Flammability Rating UL94 V-0
Dimensions
Length 40mm
Technical
Accomodates a Fuse No
Current - IEC 10A
Filter Type Unfiltered - Commercial
Voltage - IEC 250VAC
Current 15A
Number of Ports 1
Connector Style IEC 320-2-2/F
Coupling Type SNAP
Max Current Rating 15A
Max Voltage Rating (AC) 250V
Voltage 250V
Body/Shell Style PLUG
Insulation Resistance 10MOhm
Panel Cutout Dimensions Rectangular - 25.00mm x 20.00mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency cULus, ENEC
Voltage - Rated AC 250V
Current Rating 10A
Depth 31.1mm
Ingress Protection IP30
Orientation Straight
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Additional Feature STANDARDS: UL 94V-0, VDE
Gender Receptacle
Color Black
Min Operating Temperature -25°C
Max Operating Temperature 70°C
Number of Positions 3
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Solder Eyelet
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Pbfree Code yes
Series 4787
Packaging Bulk
Physical
Body Material Thermoplastic
Weight 13.000014g
Shell Material THRMOPLASTIC
Mounting Type Panel Mount, Flange
Mount Flanges, Panel, Screw
Supply Chain
Factory Lead Time 16 Weeks
