4754.6200
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
4754 RoHS Compliant GENERAL PURPOSE MULTIPLE MATING PARTS AVAILABLE Power Entry Connector Receptacle, Female Sockets 15A 250VAC 0.098 2.50mm
PDF
/
Inventory: 7226
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Panel Thickness 0.098 2.50mm
Technical
Accomodates a Fuse No
Current - IEC 10A
Filter Type Unfiltered - Commercial
Voltage - IEC 250VAC
Current - UL 15A
Connector Style IEC 320-2-2/F
Panel Cutout Dimensions Rectangular - 32.50mm x 122.10mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency CCC, cURus, VDE
Reach Compliance Code compliant
Ingress Protection IP30
Total Number of Contacts 12
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.69.40.30
Additional Feature STANDARDS: IEC/EN 60320-2-2/F; UL 94V-0; UL 498; CSA C22.2; VDE, QUICK CONNECT
Number of Positions 3 per connection (4)
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Quick Connect - 0.250 (6.3mm)
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Obsolete
Pbfree Code yes
Feature Carrier Frame, 1 Position
Series 4754
Packaging Bulk
Physical
Shell Material POLYETHYLENE
Mounting Type Panel Mount, Snap-In
