4754.3400
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
4754 RoHS Compliant GENERAL PURPOSE MULTIPLE MATING PARTS AVAILABLE Power Entry Connector Receptacle, Female Sockets 15A 250VAC 0.039 1.00mm
PDF
/
Inventory: 3914
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Panel Mount, Snap-In
Shell Material POLYETHYLENE
Technical
Packaging Bulk
Series 4754
Feature Carrier Frame, 1 Position
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Solder Eyelet
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 3 per connection (4)
Additional Feature STANDARDS: IEC/EN 60320-2-2/F; UL 94V-0; UL 498; CSA C22.2; VDE
HTS Code 8536.69.40.30
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 12
Ingress Protection IP30
Reach Compliance Code compliant
Approval Agency CCC, cURus, VDE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Panel Cutout Dimensions Rectangular - 32.50mm x 122.10mm
Connector Style IEC 320-2-2/F
Current - UL 15A
Voltage - IEC 250VAC
Filter Type Unfiltered - Commercial
Current - IEC 10A
Accomodates a Fuse No
Dimensions
Panel Thickness 0.039 1.00mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
