4307.3004
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
SPST Switch On-Off PMM ROHS3Compliant Power Entry Connector Receptacle, Female Sockets; Receptacle, Male Blades UL94V-2 10A 250V 0.059 1.50mm
PDF
/
Inventory: 4894
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-2
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-2
Dimensions
Panel Thickness 0.059 1.50mm
Technical
Switch Features Switch On-Off
Accomodates a Fuse No
Filter Type Unfiltered - Commercial
Voltage - IEC 250VAC
Throw Configuration SPST
Current 10A
Connector Style IEC 320-2-2/F; IEC 320-C14
Max Voltage Rating (AC) 250V
Body/Shell Style PLUG
Panel Cutout Dimensions Rectangular - 63.70mm x 32.20mm
Contact Gender FEMALE AND MALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency CCC, cULus, ENEC
Ingress Protection IP40
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Number of Positions 3 per connection (2)
Connector Type Receptacle, Female Sockets; Receptacle, Male Blades
Termination Quick Connect - 0.189 (4.8mm)
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Obsolete
Pbfree Code yes
Feature Cover
Series PMM
Packaging Bulk
Physical
Shell Material POLYETHYLENE
Number of Pins 1
Package / Case Module
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
