4304.4067
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
Power Entry Module Filtered M 3 POS 250VAC 2A Switch/Fuse ST 1 Port
PDF
/
Buying Options
Total Price: USD $47.7
Unit Price: USD $47.696
≥1 USD $47.696
≥10 USD $38.483456
Inventory: 89
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Flanges, Panel
Mounting Type Panel Mount, Flange, Right Angle
Package / Case Module
Shell Material STEEL
Weight 129.999998g
Technical
Packaging Bulk
Series FKI
Feature Shielded
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Quick Connect - 0.250 (6.3mm)
Connector Type Receptacle, Male Blades - Module
Number of Positions 3
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Ingress Protection IP40
Depth 55mm
Current Rating 2A
Shell Finish NICKEL
Approval Agency cULus, ENEC
Mating Information MULTIPLE MATING PARTS AVAILABLE
Panel Cutout Dimensions Rectangular - 29.50mm x 61.00mm
Body/Shell Style SOCKET
Max Voltage Rating (AC) 250V
Max Current Rating 2A
Coupling Type SNAP
Connector Style IEC 320-C14
Number of Ports 1
Current 2A
Voltage - UL 125VAC
Voltage - IEC 250VAC
Filter Type Filtered (EMI, RFI) - Commercial, Medical
Accomodates a Fuse Yes (Fuse Not Included)
Fuse Yes
Fuse Holder, Drawer Fuse Holder
Switch Features Switch On-Off
Dimensions
Height 65mm
Length 50mm
Width 50mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
