4302.5339
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
AC Power Entry Modules KFB .25QC 2-P SW 10A
PDF
/
Buying Options
Total Price: USD $51.25
Unit Price: USD $51.2512
≥1 USD $51.2512
≥10 USD $37.51
Inventory: 84
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Flanges, Panel
Mounting Type Panel Mount, Flange
Package / Case Module
Shell Material THRMOPLASTIC
Weight 80.000001g
Body Material Thermoplastic
Technical
Packaging Bulk
Series KFB2
Feature Shielded
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Quick Connect - 0.250 (6.3mm)
Connector Type Receptacle, Male Blades - Module
Number of Positions 3
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Gender Male
Voltage - Rated DC 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Ingress Protection IP40
Current Rating 10A
Voltage - Rated AC 250V
Approval Agency CCC, cULus, ENEC
Mating Information MULTIPLE MATING PARTS AVAILABLE
Panel Cutout Dimensions Rectangular - 28.50mm x 43.00mm
Max Voltage Rating (AC) 250V
Max Current Rating 10A
Coupling Type SNAP
Connector Style IEC 320-C14
Number of Ports 1
Current 10A
Voltage - UL 125VAC
Voltage - IEC 250VAC
Filter Type Filtered (EMI, RFI) - Commercial, Medical
Accomodates a Fuse No
Switch Features Switch On-Off
Dimensions
Height 59mm
Width 30.5mm
Compliance
Material Flammability Rating UL94 V-0
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
