4302.2003
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
DPST Switch On-Off KEB2 ROHS3Compliant Power Entry Connector Receptacle, Male Blades - Module UL94V-0 70C 15A 250V
PDF
/
Buying Options
Total Price: USD $13.99
Unit Price: USD $13.992
≥1 USD $13.992
≥10 USD $12.7732
≥100 USD $10.7052
Inventory: 207
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Panel Mount, Snap-In
Package / Case Module
Shell Material POLYETHYLENE
Housing Material Thermoplastic
Weight 17.600008g
Mount Panel, Snap in
Technical
Packaging Bulk
Series KEB2
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Quick Connect - 0.189 (4.8mm)
ECCN Code EAR99
Connector Type Receptacle, Male Blades - Module
Type Switch
Number of Positions 3
Max Operating Temperature 70°C
Min Operating Temperature -25°C
Color Black
Gender Male
Voltage - Rated DC 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Ingress Protection IP40
Depth 27.7mm
Current Rating 10A
Voltage - Rated AC 250V
Approval Agency CCC, CSA, UL, VDE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Panel Cutout Dimensions Rectangular - 27.50mm x 42.00mm
Body/Shell Style SOCKET
Voltage 250V
Max Voltage Rating (AC) 250V
Max Current Rating 10A
Connector Style IEC 320-C14
Number of Ports 1
Current 15A
Number of Poles 2
Throw Configuration DPST
Voltage - IEC 250VAC
Filter Type Unfiltered - Commercial
Accomodates a Fuse No
Switch Features Switch On-Off
Supply Chain
Factory Lead Time 13 Weeks
Dimensions
Length 30mm
Plating Thickness 2mm
Panel Thickness 0.079 2.00mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
