4301.5243

Schurter Inc.
RoHS
RoHS RoHS compliant
Package Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description Power Entry Module Filtered M 3 POS 250VAC 2A Fuse/Voltage Selector ST 1 Port
PDF
/
Inventory: 5538
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Flanges, Panel
Mounting Type Panel Mount, Flange
Package / Case Module
Shell Material POLYETHYLENE
Weight 43.999991g

Technical

Packaging Bulk
Series KFA
Feature Voltage Selector
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Quick Connect - 0.189 (4.8mm)
ECCN Code EAR99
Connector Type Receptacle, Male Blades - Module
Resistance 1MOhm
Number of Positions 3
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Gender Male
Voltage - Rated DC 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Ingress Protection IP40
Depth 69mm
Current Rating 2A
Voltage - Rated AC 250V
Approval Agency CCC, cULus, ENEC
Panel Cutout Dimensions Rectangular - 29.00mm x 33.00mm
Body/Shell Style PLUG
Inductance 4 mH
Max Voltage Rating (AC) 250V
Max Current Rating 2A
Coupling Type SNAP
Connector Style IEC 320-C14
Number of Ports 1
Current 2A
Voltage - UL 125VAC
Voltage - IEC 250VAC
Filter Type Filtered (EMI, RFI) - Commercial, Medical
Accomodates a Fuse Yes (Fuse Not Included)
Fuse Yes
Fuse Holder, Drawer Drawer Sold Separate

Dimensions

Height 44mm
Length 44mm
Width 34mm

Compliance

Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free

Alternative Model

FRCIR08F16S-4SF80T109

FRCIR08F16S-4SF80T109

ITT Cannon, LLC

Recommended For You

75168-327-08LF
