4301.5014
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
SCHURTER 4301.5014 INLET FILTER, IEC, C14, KFA, 6A
PDF
/
Buying Options
Total Price: USD $28.01
Unit Price: USD $28.009872
≥1 USD $28.009872
≥10 USD $26.42441
≥100 USD $24.928688
≥500 USD $23.517632
≥1000 USD $22.186446
Inventory: 950
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Flanges, Panel, Screw, Snap in
Mounting Type Panel Mount, Flange
Package / Case Module
Shell Material POLYETHYLENE
Weight 65.999986g
Body Material Thermoplastic
Technical
Packaging Bulk
Series KFA
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Quick Connect - 0.250 (6.3mm)
ECCN Code EAR99
Connector Type Receptacle, Male Blades - Module
Number of Positions 3
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Color Black
Gender Male
Capacitance 68nF
Voltage - Rated DC 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Ingress Protection IP40
Depth 60.5mm
Current Rating 6A
Voltage - Rated AC 250V
Approval Agency CCC, cULus, ENEC
Panel Cutout Dimensions Rectangular - 29.00mm x 33.00mm
Body/Shell Style PLUG
Max Voltage Rating (AC) 250V
Max Current Rating 6A
Connector Style IEC 320-C14
Current 6A
Number of Poles 1
Voltage - UL 125VAC
Voltage - IEC 250VAC
Filter Type Filtered (EMI, RFI) - Commercial
Accomodates a Fuse Yes (Fuse Not Included)
Fuse Yes
Fuse Holder, Drawer Drawer Sold Separate
Dimensions
Height 44mm
Length 34mm
Width 34mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
