4301.2041
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
SCHURTER 4301.2041 INLET, IEC, C14, KEA, 10A
PDF
/
Buying Options
Total Price: USD $8.43
Unit Price: USD $8.4304
≥1 USD $8.4304
≥10 USD $6.14328
≥100 USD $4.83472
≥500 USD $4.731091
Inventory: 98
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Length 44mm
Technical
Fuse Holder, Drawer Fuse Holder
Fuse Yes
Fuse Current 10A
Accomodates a Fuse Yes (Fuse Not Included)
Filter Type Unfiltered - Commercial
Voltage - IEC 250VAC
Number of Poles 2
Current 10A
Number of Ports 1
Connector Style IEC 320-C14
Coupling Type SNAP
Max Current Rating 10A
Max Voltage Rating (AC) 250V
Voltage 250V
Body/Shell Style SOCKET
Panel Cutout Dimensions Rectangular - 27.50mm x 31.50mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency CCC, CSA, ENEC, UL
Voltage - Rated AC 250V
Frequency 50Hz
Current Rating 10A
Depth 41.4mm
Ingress Protection IP40
Orientation Straight
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Gender Male
Min Operating Temperature -25°C
Max Operating Temperature 70°C
Number of Positions 3
Connector Type Receptacle, Male Blades - Module
ECCN Code EAR99
Termination Quick Connect - 0.189 (4.8mm)
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Pbfree Code yes
Feature Front or Rear Side Mount, V-Lock Notch, Voltage Selector
Series KEA
Packaging Bulk
Physical
Body Material Thermoplastic
Weight 19.999993g
Shell Material POLYETHYLENE
Package / Case Module
Mounting Type Panel Mount, Flange
Mount Flanges, Panel, Screw
Supply Chain
Factory Lead Time 9 Weeks
