FN9280E-2-06
RoHS
/
Package /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
AC Power Entry Modules 2A SINGLE STAGE FLTR FLANGE MOUNT
PDF
/
Buying Options
Total Price: USD $31.63
Unit Price: USD $31.627675
≥1 USD $31.627675
≥10 USD $29.837428
≥100 USD $28.148519
≥500 USD $26.55521
≥1000 USD $25.052086
Inventory: 9407
Minimum: 1
-
+
Technical Details
Physical
Contact Material NOT SPECIFIED
Mount Panel
Mounting Type Panel Mount, Flange
Weight 136.000005g
Technical
Packaging Bulk
Published 2002
Series FN 9280
Feature Front or Rear Side Mount
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Quick Connect - 0.250 (6.3mm)
ECCN Code EAR99
Connector Type Receptacle, Male Blades - Module
Number of Positions 3
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Gender Male
Voltage - Rated 250V
Contact Finish - Mating NOT SPECIFIED
Ingress Protection IP40
Depth 80.6mm
Current Rating 2A
Frequency 400Hz
Voltage - Rated AC 250V
Approval Agency CQC, CSA, ENEC, UR
Panel Cutout Dimensions Rectangular - 28.80mm x 47.10mm
Inductance 4.4 mH
Connector Style IEC 320-C14
Voltage - UL 250VAC
Filter Type Filtered (EMI, RFI) - Commercial, Medical
Accomodates a Fuse Yes (Fuse Not Included)
Fuse Yes
Fuse Holder, Drawer Fuse Holder, Twin Fused
Switch Features Switch On-Off
Dimensions
Height 62.2mm
Length 49.8mm
Width 32mm
Panel Thickness 0.039 ~ 0.098 1.00mm ~ 2.50mm
Compliance
Material Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
