FN9264S-6-06
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
SCHAFFNER FN9264S-6-06IEC FILTER 6A HIGH PERFORMANCE SNAP FIT
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Package / Case Module
Technical
Packaging Tray
Published 2014
Series FN 9264
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect - 0.250 (6.3mm)
Connector Type Receptacle, Male Blades - Module
Number of Positions 3
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Gender Male
Voltage - Rated DC 250V
Orientation Straight
Ingress Protection IP40
Depth 65.3mm
Current Rating 6A
Frequency 400Hz
Voltage - Rated AC 250V
Approval Agency CQC, CSA, ENEC, UL
Panel Cutout Dimensions Rectangular - 29.50mm x 33.00mm
Max Voltage Rating (AC) 250V
Max Current Rating 6A
Connector Style IEC 320-C14
Number of Ports 1
Current 6A
Voltage - UL 250VAC
Filter Type Filtered (EMI, RFI) - Commercial
Accomodates a Fuse No
Switch Features Switch On-Off
Dimensions
Length 35mm
Panel Thickness 0.039 ~ 0.098 1.00mm ~ 2.50mm
Compliance
Material Flammability Rating UL94 V-2
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
