FN9244EB-15-06
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
FN 9244E RoHS Compliant 2014 GENERAL PURPOSE Power Entry Connector Receptacle, Male Blades 400Hz UL94V-2 15A 250VAC
PDF
/
Buying Options
Total Price: USD $11.45
Unit Price: USD $11.446807
≥1 USD $11.446807
≥10 USD $10.798881
≥100 USD $10.187619
≥500 USD $9.610959
≥1000 USD $9.066941
Inventory: 3006
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Flanges, Panel, Screw
Mounting Type Panel Mount, Flange
Technical
Packaging Tray
Published 2014
Series FN 9244E
Feature Bleed Resistor, Earth Line Choke, Front or Rear Side Mount
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect - 0.250 (6.3mm)
ECCN Code EAR99
Connector Type Receptacle, Male Blades
Number of Positions 3
Gender Male
Voltage - Rated 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Ingress Protection IP40
Depth 52.3mm
Current Rating 15A
Frequency 400Hz
Voltage - Rated AC 250V
Approval Agency CQC, CSA, ENEC, UL
Panel Cutout Dimensions Rectangular - 28.50mm x 21.50mm
Coupling Type SNAP
Connector Style IEC 320-C14
Current 15A
Voltage - UL 250VAC
Filter Type Filtered (EMI, RFI) - Commercial, Medical
Accomodates a Fuse No
Dimensions
Height 22.5mm
Width 48mm
Compliance
Material Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
