FN9233B-3-06
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
FN 9233 RoHS Compliant 2014 GENERAL PURPOSE Power Entry Connector Receptacle, Male Blades 400Hz UL94V-2 4.6mH 85C
PDF
/
Buying Options
Total Price: USD $6.3
Unit Price: USD $6.298992
≥1 USD $6.298992
≥10 USD $5.942452
≥100 USD $5.606085
≥500 USD $5.288757
≥1000 USD $4.989393
Inventory: 1148
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Flanges, Panel, Screw
Mounting Type Panel Mount, Flange
Package / Case Module
Technical
Packaging Tray
Published 2014
Series FN 9233
Feature Bleed Resistor, Front or Rear Side Mount
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect - 0.250 (6.3mm)
ECCN Code EAR99
Connector Type Receptacle, Male Blades
Number of Positions 3
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Gender Male
Voltage - Rated 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Ingress Protection IP40
Depth 43.9mm
Current Rating 3A
Frequency 400Hz
Voltage - Rated AC 250V
Approval Agency CQC, CSA, ENEC, UL
Panel Cutout Dimensions Rectangular - 28.50mm x 21.50mm
Inductance 4.6 mH
Coupling Type SNAP
Connector Style IEC 320-C14
Current 3A
Voltage - UL 250VAC
Filter Type Filtered (EMI, RFI) - Commercial, Medical
Accomodates a Fuse No
Dimensions
Height 22.5mm
Length 20.1mm
Width 22.5mm
Compliance
Material Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
