FN9233-15-06
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
AC Power Entry Modules 15A 250VAC 50/60Hz mounting flanges
PDF
/
Buying Options
Total Price: USD $4.66
Unit Price: USD $4.664
≥1 USD $4.664
≥10 USD $4.21696
≥100 USD $3.983584
≥500 USD $3.8863
≥1000 USD $3.69197
≥3000 USD $3.421
Inventory: 31
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Flanges, Panel, Screw
Mounting Type Panel Mount, Flange
Package / Case Module
Technical
Packaging Tray
Published 2008
Series FN 9233
Feature Front or Rear Side Mount
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Quick Connect - 0.250 (6.3mm)
ECCN Code EAR99
Connector Type Receptacle, Male Blades
Number of Positions 3
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Gender Male
Capacitance 100nF
Voltage - Rated DC 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Ingress Protection IP40
Depth 82.3mm
Current Rating 15A
Frequency 400Hz
Voltage - Rated AC 250V
Approval Agency CQC, CSA, ENEC, UL
Panel Cutout Dimensions Rectangular - 28.50mm x 21.50mm
Inductance 200 μH
Max Voltage Rating (AC) 250V
Max Current Rating 15A
Coupling Type SNAP
Connector Style IEC 320-C14
Number of Ports 1
Current 15A
Voltage - UL 250VAC
Filter Type Filtered (EMI, RFI) - Commercial
Accomodates a Fuse No
Dimensions
Height 22.5mm
Length 48mm
Width 22.5mm
Compliance
Material Flammability Rating UL94 V-2
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
