FN379B-4-22
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
SINGLE PHASE IEC-INLET PEM,4 A FILTER, 100/120/220/240V 2 FUSE US FORMAT
PDF
/
Inventory: 5123
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-2
Dimensions
Panel Thickness 0.031 ~ 0.126 0.79mm ~ 3.20mm
Width 50mm
Height 58mm
Technical
Fuse Holder, Drawer Fuse Holder, Twin Fused
Fuse Yes
Accomodates a Fuse Yes (Fuse Not Included)
Filter Type Filtered (EMI, RFI) - Commercial, Medical
Voltage - UL 250VAC
Current 4A
Connector Style IEC 320-C14
Coupling Type SNAP
Panel Cutout Dimensions Variable Size
Approval Agency CSA, UL, VDE
Voltage - Rated AC 250V
Frequency 400Hz
Current Rating 4A
Depth 70mm
Ingress Protection IP40
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Voltage - Rated 250V
Gender Male
Number of Positions 3
Connector Type Receptacle, Male Blades - Module
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Bleed Resistor, Front or Rear Side Mount, Voltage Selector
Series FN 370
Published 2009
Packaging Bulk
Physical
Package / Case Module
Mounting Type Panel Mount, Flange
Mount Flanges, Panel, Screw
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 10 Weeks
