FN283-2-06
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
PWR ENT MOD RCPT IEC320-C14 PNL
PDF
/
Buying Options
Total Price: USD $25.92
Unit Price: USD $25.916
≥1 USD $25.916
≥10 USD $22.69256
≥100 USD $21.711712
≥500 USD $21.01132
≥1000 USD $20.31084
≥3000 USD $19.190274
Inventory: 101
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Flanges, Panel, Screw
Mounting Type Panel Mount, Flange
Package / Case Module
Technical
Packaging Tray
Published 2011
Series FN 280
Feature Front or Rear Side Mount
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Quick Connect - 0.250 (6.3mm)
ECCN Code EAR99
Connector Type Receptacle, Male Blades - Module
Resistance 1MOhm
Number of Positions 3
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Gender Male
Additional Feature STANDARDS: CSA, UL
Capacitance 220nF
Voltage - Rated DC 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance YES
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Ingress Protection IP40
Depth 43.1mm
Current Rating 2A
Switch Features Switch On-Off
Fuse Holder, Drawer Fuse Holder
Fuse Yes
Accomodates a Fuse Yes (Fuse Not Included)
Filter Type Filtered (EMI, RFI) - Commercial
Voltage - UL 250VAC
Current 2A
Number of Ports 1
Connector Style IEC 320-C14
Coupling Type SNAP
Max Current Rating 2A
Max Voltage Rating (AC) 250V
Leakage Current 350μA
Inductance 2 mH
Panel Cutout Dimensions Rectangular - 29.00mm x 60.00mm
Approval Agency CQC, CSA, ENEC, UL
Voltage - Rated AC 250V
Frequency 400Hz
Compliance
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Material Flammability Rating UL94 V-2
Dimensions
Width 65mm
Length 50mm
Height 65mm
