739W-X2/20
RoHS
RoHS compliant
RoHS compliantPackage 125
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
PWR ENT RCPT NEMA5-20 PANEL IDC
PDF
/
Buying Options
Total Price: USD $1.45
Unit Price: USD $1.452
≥1 USD $1.452
≥10 USD $1.26192
≥100 USD $1.207712
≥500 USD $1.18096
≥1000 USD $1.127368
≥3000 USD $1.019982
Inventory: 16016
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Dimensions
Panel Thickness 0.031 ~ 0.071 0.79mm ~ 1.80mm
Technical
Accomodates a Fuse No
Filter Type Unfiltered - Commercial
Voltage - UL 125VAC
Number of Poles 2
Current 20A
Connector Style NEMA 5-20R
Panel Cutout Dimensions Square - 24.50mm x 24.50mm
Approval Agency cUL, UL
Current Rating 20A
Voltage - Rated DC 125V
Voltage - Rated 125V
Gender Receptacle
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 70°C
Number of Positions 3
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Terminating Cover
Series 739W
Published 2007
Packaging Bulk
Physical
Housing Material Nylon
Package / Case 125
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Plating Copper
Contact Material Bronze
Supply Chain
Factory Lead Time 20 Weeks
