716W-X2/01
RoHS
RoHS compliant
RoHS compliantPackage 100
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
PWR ENT RCPT IEC320-2-2F PANEL
PDF
/
Buying Options
Total Price: USD $1.56
Unit Price: USD $1.555787
≥1 USD $1.555787
≥200 USD $0.621002
≥500 USD $0.599995
≥1000 USD $0.589492
Inventory: 9457
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Panel Thickness 0.031 ~ 0.059 0.79mm ~ 1.50mm
Width 27.6mm
Length 35.1mm
Height 24.6mm
Technical
Accomodates a Fuse No
Current - IEC 10A
Filter Type Unfiltered - Commercial
Voltage - IEC 250VAC
Number of Poles 2
Current 15A
Connector Style IEC 320-2-2/F
Max Current Rating 15A
Max Voltage Rating (AC) 250V
Panel Cutout Dimensions Rectangular - 32.60mm x 25.30mm
Approval Agency CSA, UL, VDE
Voltage - Rated AC 250V
Current Rating 15A
Orientation Straight
Voltage - Rated DC 250V
Gender Receptacle
Number of Positions 3
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Solder Eyelet
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series 716W
Published 2007
Packaging Bulk
Physical
Housing Material Thermoplastic
Package / Case 100
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Material Copper
Supply Chain
Factory Lead Time 20 Weeks
