10NB3S
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
SINGLE 250V 10A IEC SNAP-IN N/A-LUG
PDF
/
Buying Options
Total Price: USD $33.26
Unit Price: USD $33.263634
≥1 USD $33.263634
≥192 USD $13.272106
≥480 USD $12.829659
≥960 USD $12.610405
Inventory: 1192
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Panel Thickness 0.031 ~ 0.126 0.79mm ~ 3.20mm
Technical
Switch Features Switch On-Off
Fuse Holder, Drawer Fuse Holder
Accomodates a Fuse Yes (Fuse Not Included)
Filter Type Filtered (EMI, RFI) - Commercial
Voltage - IEC 115/250VAC
Current 10A
Number of Ports 1
Connector Style IEC 320-C14
Max Current Rating 10A
Max Voltage Rating (AC) 250V
Panel Cutout Dimensions Variable Size
Approval Agency CSA, UL, VDE
Voltage - Rated AC 115V
Frequency 30MHz
Current Rating 10A
Reach Compliance Code unknown
Orientation Straight
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Additional Feature STANDARDS: CSA; UL; VDE
Number of Positions 3
Connector Type Receptacle, Male Blades - Module
ECCN Code EAR99
Termination Solder Eyelet
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series NB
Published 2008
Packaging Bulk
Physical
Package / Case Module
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Supply Chain
Factory Lead Time 18 Weeks
