06NB3M
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
PWR ENT MOD RCPT IEC320-C14 PNL
PDF
/
Inventory: 3636
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Panel Thickness 0.031 ~ 0.126 0.79mm ~ 3.20mm
Length 58mm
Technical
Switch Features Switch On-Off
Fuse Holder, Drawer Fuse Holder, Twin Fused
Fuse Yes
Accomodates a Fuse Yes (Fuse Not Included)
Filter Type Filtered (EMI, RFI) - Commercial, Medical
Voltage - IEC 115/250VAC
Number of Ports 1
Connector Style IEC 320-C14
Max Current Rating 6A
Max Voltage Rating (AC) 250V
Panel Cutout Dimensions Variable Size
Approval Agency CSA, UL, VDE
Voltage - Rated AC 115V
Frequency 30MHz
Current Rating 6A
Reach Compliance Code unknown
Depth 60mm
Orientation Straight
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature CSA; UL
Gender Male
Number of Positions 3
Connector Type Receptacle, Male Blades - Module
Termination Solder Eyelet
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series NB
Published 2002
Packaging Bulk
Physical
Package / Case Module
Mounting Type Panel Mount, Snap-In
Mount Flanges, Panel, Snap in
Supply Chain
Factory Lead Time 18 Weeks
