04BEEG3S
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
SINGLE 250V 4A IEC SCREW N/A-LUG
PDF
/
Buying Options
Total Price: USD $10.93
Unit Price: USD $10.92616
≥1 USD $10.92616
≥10 USD $10.307699
≥100 USD $9.72424
≥500 USD $9.173817
≥1000 USD $8.654542
Inventory: 1529
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Flanges, Panel
Mounting Type Panel Mount, Flange
Package / Case Module
Technical
Packaging Bulk
Published 2008
Series BE
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
ECCN Code EAR99
Connector Type Receptacle, Male Blades - Module
Number of Positions 3
Additional Feature STANDARDS: CSA; UL; VDE
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation Straight
Reach Compliance Code unknown
Current Rating 4A
Frequency 30MHz
Voltage - Rated AC 115V
Approval Agency CSA, UL, VDE
Panel Cutout Dimensions Rectangular - 29.00mm x 33.00mm
Max Voltage Rating (AC) 115V
Max Current Rating 4A
Coupling Type SNAP
Connector Style IEC 320-C14
Number of Ports 1
Voltage - IEC 115/250VAC
Filter Type Filtered (EMI, RFI) - Commercial
Accomodates a Fuse Yes (Fuse Not Included)
Fuse Yes
Fuse Holder, Drawer Fuse Holder
Dimensions
Height 44.5mm
Compliance
RoHS Status ROHS3 Compliant
