PX0691/15/63
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
AC Power Entry Modules SNAP-FIT 1.5MM PANEL 6.3MM TAB
PDF
/
Inventory: 1544
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Panel Thickness 0.059 1.50mm
Technical
Accomodates a Fuse No
Current - IEC 10A
Filter Type Unfiltered - Commercial
Voltage - IEC 250VAC
Current 15A
Connector Style IEC 320-C18
Max Current Rating 10A
Max Voltage Rating (AC) 250V
Panel Cutout Dimensions Rectangular - 27.40mm x 19.80mm
Number of Contacts 2
Approval Agency CSA, ENEC, UL, VDE
Orientation Straight
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating TIN
Min Operating Temperature -40°C
Max Operating Temperature 70°C
Number of Positions 3
Connector Type Receptacle, Male Blades
ECCN Code EAR99
Termination Quick Connect - 0.250 (6.3mm)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PX
Published 2010
Packaging Bulk
Physical
Shell Material POLYAMIDE
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Material BRASS
Supply Chain
Factory Lead Time 24 Weeks
